HESS-T-012 series serial communication server is a converter between asynchronous serial port RS-232 and Ethernet port. This product is an independent intelligent device with CPU and complete TCP/IP protocol stack. The server can complete bidirectional transparent data transmission between RS-232 and Ethernet, so that RS-232 serial port devices can connect to the network immediately. The converter provides a Web configuration interface, and users can flexibly set the operating parameters of the converter. Small size and industrial-grade high-standard design are convenient for customers to install and use.
Hardware
| Processor | 32bit 120MHZ |
| RAM | 256K |
| Ethernet Interface | 10/100M (Embedded 1.5KV Electromagnetic isolation) Adaptive MDI/MDI-XEthernet Interface, Interface Mode RJ45 |
| Serial Standard | RS-232 |
| Serial RS-232 Port | RJ45 |
| Indicator Light | Power Indicator Light: PWR, Running Indicator Light: RUN, Serial Port 1 and Serial Port 2 Transmit and Receive Indicator: T/R1, T/R2 |
| Power Connector | DC-JACK, 5.08 3-pin Terminal Block |
| Power Range | DC 5V, ±5% |
| Max. Power Consumption | 5V @90mA |
| Housing | Metal Housing |
| Installation | Din-rail Mounted |
| Electrostatic Protection | Air 4kV, Contact 4kV |
| Surge Protection | Serial Port 600W |
| Operating Environment | Storage Temperature: -40~85°C Operating Temperature: -40~85°C Relative Humidity: 5% ~95% (Non-condensing) |
| Dimensions L×W×H | 100mm×80.8mm×30mm (Excluding Mounting Parts) |
Software
| Protocol Support | ARP, IP, ICMP, UDP, TCP, HTTP, DHCP, SNMP |
| Configuration Method | VCOM Utility (Virtual COM Only Windows) |
| Baud Rate | 300 - 921, 600bps |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 2 |
| Check Bits | None, Odd, Even |
| Flow Control | RTS/CTS, XON/XOFF |
