Layer 2 Managed Industrial Ethernet Switch

Manufacturer Part Number: HES16MB-TB

$ 1100.00

16 × 10/100Mbps RJ45 Copper Ports
Supports IGMP Snooping,IEEE 802.1Q VLAN,QoS,STP/RSTP,SNMPv1/v2/v3 and Other Protocols to Insure Safe and Stable Network
Adopts RMON to Improve Network Monitor Forecast Ability
Supports Port Isolation and ACL Function
Supports Trap and RMON
Supports Port Speed Limit and Broadcast Storm Suppression
Supports LLDP,Link Flap,UDLD,DDM
Working Temperature -10°C to 60°C Is Supported

See our Shipping Policy for delivery regions and fees

Backordered

More stock available: July 5, 2026 (UTC-4)

HES16MA-TB/HES16MB-TB series is managed industrial Ethernet switches. It supports 16 10/100Mbps copper ports. This series supports one console port which provides CL management. It also supports Ethernet Layer 2 protocols required for industrial sites to ensure the stability of the communication network. This series switches adopts a low-power, fanless design to ensure no noise interference, while -40~75℃ operating temperature and good EMC electromagnetic compatibility performance are ensuring stable operation in harsh industrial environments.

Ethernet Interface

10/100/BaseT(X) Port (RJ45 Connector)	16 Full/Half Duplex Mode; Auto MDI/MDI-X Adaptive; Auto Negotiation Speed
Console Port	1
Standard	IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3z, IEEE8O2.1Q, IEEE802.1p, IEEE802.1D, IEEE802.1W, IEEE802.1S, IEEE802.3ad, IEEE802.1x

Ethernet Software Features

Protocols	ARP, ICMP, TCP, HTTP, HTTPS, Telnet, STP/RSTP/ MSTP, LLDP, IGMP, SNMPv1/v2c/v3, DHCP Server, UDLD, NTP, RMON, Syslog
Flow Control	IEEE802.3x Flow Control, Backpressure Flow Control

Switch Properties

Processing Type	Store and Forward
MAC Table Size	8K
Packet Buffer Size	4.1MB
Backplane Bandwidth	32GB
Max. Frame Length	10KB

Power Parameters

Input Voltage	12/24/48 VDC (10.8~52.8VDC), Redundant Dual Power Input
Power Consumption	375mA@24Vmax

Physical Characteristics

Case	Metal Enclosure, IP40 Design
Installation	Din-rail Mounted
Dimensions (Width × Height × Depth)	1.65" × 5.91" × 4.72" （42mm x 150mm x 120mm）

Environmental Limits

Working Temperature	-10℃ ~ 60℃
Storage Temperature	-40℃ ~ 85℃
Relative Humidity	0% ~ 95% (No Condensation)

Industrial Standard

EMI	FCC Part15, CISPR (EN55022) Class A
EMS	EN61000-4-2(ESD) EN61000-4-3(RS) EN61000-4-4(EFT) EN61000-4-5(Surge) EN61000-4-6(CS) EN61000-4-8 (Power Frequency Magnetic Field)
Shock	IEC 60068-2-27
Freefall	IEC 60068-2-32
Vibration	IEC 60068-2-6

Warranty

5 years
