Predision HES4G-T-020 Industrial 1-port (RS-232/422/485) Serial to Wi-Fi Device
Manufacturer Part Number: HES4G-T-020
Brand: Predision
$ 200.00
- 1 x RS-232/422/485 Software Selectable Serial Port
- Power Supply: 12 - 36 VDC
- Baud Rate: 300 - 921,600 bps
- Resistance: 50Ω (Glue Stick Antenna)
- Supports 802.11b/g/n Wireless Standard
- Supports Wireless STA/AP/AP+STA Operating Mode
- Supports AT Command and Web Interface Settings
See our Shipping Policy for delivery regions and fees
The HES4G-T-020 is an industrial-grade wireless serial device server designed for bidirectional conversion between RS-232/485/422 and Wi-Fi networks. Built to rigorous industrial standards, it ensures mission-critical reliability in demanding environments.
Featuring multiple operation modes, the HES4G-T-020 offers flexible configuration via AT commands or an intuitive Web interface, enabling seamless bridging between wired and wireless infrastructures. With integrated surge protection and a robust hardware design, this server is an ideal solution for remote data communication and advanced industrial automation.
Featuring multiple operation modes, the HES4G-T-020 offers flexible configuration via AT commands or an intuitive Web interface, enabling seamless bridging between wired and wireless infrastructures. With integrated surge protection and a robust hardware design, this server is an ideal solution for remote data communication and advanced industrial automation.
| Antenna | 2.4 GHz Wi-Fi, ESP32 Module, External Antenna |
| Wireless Standard | 802.11 b/g/n |
| Frequency Range | 2,412 - 2,484 MHz |
| Power Input | 12-36 VDC |
| Power Interface | DC-JACK |
| Power Protection | Surge Protection: 1.2/50 μs, Common Mode 2 kV / Differential Mode 1 kV |
| Operating Current | 200 mA @ 12 V Max |
| Serial Port | 1 × Multiplexed RS-485/422/232 Port, with Baud Rate Configurable from 300 bps to 921.6 kbps |
| Serial Port Connector | RS-485/422: 5.08mm-pitch (0.2-inch) 4-pin Phoenix Terminal RS-232: DB9 Male Connector |
| Serial Port Protection | Surge Protection: 10/700 μs, Common Mode 2 kV / Differential Mode 1kV (RS-485/422); 600W per wire (RS-232) |
| Button | Button for Restoring Factory Settings |
| Signal Indicators | Five LEDs for Power (PWR), Transmit (TXD), Receive (RXD), Wireless (WIRELESS) and Status (STATUS) |
| Operating Temperature & Storage Temperature | -40℃ to 85℃ |
| Operating Humidity & Storage Humidity | 5 - 95% (No Condensation) |
| Dimension | 3.82" x 2.56" x 0.87" (97 mm x 65 mm x 22 mm) (Excluding Antenna) |
| IP Level | IP30 |
| Electrostatic Protection | Contact 6kV, Air 8kV |
| Output Power | 72.2 Mbps PA Output Power: 15 dBm (Max) 11b Mode PA Output Power: 20.5 dBm (Max) |
| Sensitivity | DSSS, 1Mbps: -98 dBm CCK, 11Mbps: -91 dBm DFDM, 6Mbps: -93 dBm DFDM, 54Mbps: -75 dBm HT20, MCS0: -93 dBm HT20, MCS7: -73 dBm HT40, MCS0: -90 dBm HT40, MCS7: -70 dBm MCS32: -89 dBm |
Industrial 1-port (RS-232/422/485) Serial to Wireless Device, Power Supply: 12 - 36 VDC, Operating Modes: STA, AP, AP+STA, Surge Protection: 10/700 μs, Common Mode 2 kV / Differential Mode 1kV (RS-485/422); 600W per wire (RS-232), Operating Temperature: -40℃ to 85℃.
