Predision HEUS-T-024 USB to 4-port RS-232 Converter
Manufacturer Part Number: HEUS-T-024
Brand: Predision
$ 195.00
- Operating Temperature: -40°C to 85°C
- ±15 kV ESD Protection
- Baud Rate: 300 - 921,600 bps
- Supports 4 x RS-232 Port
See our Shipping Policy for delivery regions and fees
10 Available
The HEUS-T-024 is a high-performance, industrial-grade USB to 4-port RS-232 converter designed for seamless integration with USB and RS-232 standards. As a bus-powered device, it operates without the need for an external power supply, efficiently converting single-ended USB signals into four independent RS-232 channels.
Featuring unique I/O circuitry with zero-delay automatic transceiver technology, the converter intelligently manages data flow direction to ensure true plug-and-play functionality across all modern communication software and hardware. The HEUS-T-024 supports reliable point-to-point communication with high-speed data transmission rates ranging from 300–921,600 bps. For rapid diagnostics and monitoring, the device includes dedicated LED indicators for power and data traffic status.
| Standard | USB 1.0/1.1/2.0; EIA RS-232 |
| USB Signals | VCC, DATA-, DATA+, GND, FG |
| RS-232 Signals | DCD, RXD, TXD, DTR, GND, DSR, RTS, CTS, RI |
| Operating Mode | Asynchronous, Point-to-point Mode |
| Direction Control | Integrated Automatic Data Flow Control technology automatically detects and manages the data transmission direction |
| Baud Rate | 300 - 921,600 bps with Auto-Baud Detection |
| Transmission Distance | Up to 5 m (USB and RS-232) |
| Interface Protection | Surge Protection, ±15 kV ESD Protection |
| Interface Connector | Type-A Male (USB), DB9 Male (RS-232) |
| LED Indicators | Three LEDs for Power (PWR), Transmit (TXD) and Receive (RXD) |
| Transmission Medium | Twisted-pair (UTP) or Shielded Cable (STP) |
| Cable Length | 1500 mm |
| Operating Temperature | -40°C to 85°C; Relative Humidity: 5% to 95% |
| OS Support | • Windows 2000, Server 2003, Server 2008, Windows 7, Windows 7 x 64 • Windows XP and XP 64-bit • Windows Vista and Vista 64-bit • Windows XP Embedded • Windows CE 4.2, 5.0, 5.2 and 6.0 • Mac OS-X • Linux |
USB to RS-232 Converter, Screw-fixed Plastic Housing, 1.5 m Cable, USB 2.0 Full Speed, Baud Rate: 300 - 115,200 bps with Auto-Baud Detection, Transmission Distance: 15m for RS-232 Port, 5m for USB Port, ±15 kV ESD Protection, Operating Temperature: -25℃ to 70℃.
USB to RS-232 Converter, Screw-fixed Plastic Housing, 1.5 m Cable, USB 2.0 Full Speed, Baud Rate: 300 - 460,800 bps with Auto-Baud Detection, Transmission Distance: Up to 5m (USB and RS-232), ±15 kV ESD Protection, Operating Temperature: -40℃ to 85℃.
USB to RS-232 Converter (USB 2.0), Photoelectric Isolated, Aluminum Enclosure, Baud Rate: 300 - 460,800 bps with Auto-Baud Detection, Transmission Distance: Up to 5m (USB and RS-232), ±15 kV ESD, Operating Temperature: –40℃ to 85℃.
USB to RS-232 Converter (USB 2.0); 1.5 m Cable; Baud Rate: 300–460,800 bps with Auto-Baud Detection; Transmission Distance: Up to 5m (USB and RS-232); ±15 kV ESD Protection; Operating Temperature: –40°C to 85°C.
USB to RS-232 Converter (USB 2.0), 1.5 m Cable, Baud Rate: 300 - 460,800 bps with Auto-Baud Detection, Transmission Distance: Up to 5m (USB and RS-232), ±15 kV ESD Protection, Operating Temperature: -40℃ to 85℃.
USB to RS-232 Converter (USB 2.0), Screw-fixed Plastic Housing, 1.5 m Cable, Baud Rate: 300 bps - 460.8 Kbps, USB Port-powered, ±15 kV ESD Protection, Operating Temperature: -40℃ to 85℃.
USB to RS-232 Converter (USB 2.0), 1.5 m Cable, Baud Rate: 300 - 115.2 Kbps, USB Port-powered, ±15 kV ESD Protection, Operating Temperature: -40℃ to 85℃.
USB to RS-232 Console Cable, 1.5 m, Baud Rate: 300 - 460,800 bps with Auto-Baud Detection, Transmission Distance: Up to 5 m (USB and RS-232), ±15 kV ESD Protection, Operating Temperature: -40°C to 85°C.
USB to RS-232 Converter (USB 2.0), Screw-fixed Plastic Housing, Baud Rate: 300 - 460,800 bps with Auto-Baud Detection, Transmission Distance: Up to 5 m (USB and RS-232), ±15 kV ESD Protection, Operating Temperature: -40℃ to 85℃.
USB to 2-port RS-232 Converter with Optical Isolation, Aluminum Enclosure, Baud Rate: 300 - 115,200 bps with Auto-Baud Detection, Surge Protection: 3,000 A (8/20 μs Waveform) on the RS-232 Port, Operating Temperature: -40℃ to 85℃.
USB to 4-port RS-232 Converter (USB 2.0), Screw-Fixed Plastic Housing, 1.5 m Cable, Baud Rate: 300 - 921,600 bps with Auto-Baud Detection, Transmission Distance: Up to 5 m (USB and RS-232), ±15 kV ESD Protection, Operating Temperature: -40℃ to 85℃.
USB to 8-port RS-232 Serial Converter (USB 2.0), 1U Rack-Mount Metal Enclosure, Power Input: 220 V AC, 50 Hz, Baud Rate: 300 bps - 921.6 Kbps with Auto-Baud Detection, ±15 kV ESD Protection, Operating Temperature: -25℃ to 70℃.
