Name: Predision HECS-T-006 100M Fiber to 2-port CAN-Bus Converter
Brand: Predision
Price: 279.00 USD
Availability: OutOfStock

account&orders

Home

Predision HECS-T-006 100M Fiber to 2-port CAN-Bus Converter 1

Predision HECS-T-006 100M Fiber to 2-port CAN-Bus Converter

Manufacturer Part Number: HECS-T-006

Brand: Predision

$ 279.00

Bidirectional Data Transmission between CAN-bus and Fiber Optic Network
Supports CAN 2.0 Protocol
2-port CAN-bus Communication Interface with 5 Kbps ~ 1 Mbps Customized Rate
1-port 100M Fiber Optic Network Interface
-40°C to 85°C Operating Temperature

See our Shipping Policy for delivery regions and fees

Backordered

More stock available: May 31, 2026 (UTC-4)

The HECS-T-006 is a high-performance communication gateway integrating dual CAN interfaces and a 100M optical fiber port. By bridging CAN-bus networks with fiber optics at rates ranging from 5 Kbps to 1 Mbps, it significantly extends the reach and scalability of CAN-based systems.

Featuring an intuitive Web-based configuration interface, the HECS-T-006 allows for flexible parameter management. Engineered to rigorous industrial standards, the device provides full galvanic isolation between the communication interfaces and the system logic. This robust design ensures superior EMC performance, surge protection, and noise immunity, making it an ideal solution for mission-critical industrial control and data acquisition environments.

Max. Transmission Distance	20Km
Operating Voltage	12-36 VDC
Operating Current	150 mA @ 12 V
Operating Temperature	-40℃ to 85℃
Storage Temperature	-40℃ to 85℃
Operating Humidity	5~95% (Non-condensing)
Storage Humidity	5~95% (Non-condensing)
Isolation Voltage	1,000 VDC
Static Protection	Air 8kV, Contact 6kV
Surge Protection	Power Port: 1.2/50us Common Mode 2kV, Differential Mode 1kV CAN Cort: 600W

HECS-T-002

RS-232 to CAN BUS Converter, CAN 2.0 Protocol, Transmission Rate 5Kbps-1Mbps for Can bus Interface, Transmission Rate 600bps-230.4Kbps for RS-232 Interface, Operating Voltage: 12-36 VDC, Operating Temperature: -40 ~ 85℃, Isolated Voltage: 1,000 VDC

HECS-T-003

RS-232/485 to CAN BUS Converter, Supports CAN 2.0 Protocol, Transmission Rate 5 Kbps - 1 Mbps for Can bus Interface, Transmission Rate 600 bps - 230.4 Kbps for RS-232 Interface, Operating Voltage: 12-36 VDC, Operating Temperature: -40℃ to 85℃, Isolation Voltage: 1,000 VDC

HECS-T-004

USB/RS-232 to CAN Bus Protocol Converter, Din-rail, Iron Enclosure, Operating Voltage: 12-36 VDC/USB Power Supply, Operating Temperature: -40°C to 85°C

HECS-T-005

PCI-E to 2-port CAN Bus Card, 4U, Bus: X1 2.5 Gbps PCI Express, CAN Communication Transmission Rate: 500 bps-1,000 Kbps, Surge Protection: 8/20 Waveform 3,000A, Isolated Voltage 1,500 VDC, Working Temperature: -40 - 85°C

HECS-T-006

100M Fiber to 2-port CANBUS Converter, Din-rail Mounting, Iron Enclosure, Supports CAN2.0 Protocol, Operating Voltage: 12-36 VDC, Operating Temperature: -40°C to 85°C, Isolation Voltage: 1,000 VDC

HECS-T-008

TCP/IP to 2-port CAN Bus Converter, Din-rail, Iron Enclosure, Supports CAN 2.0 Protocol, Operating Voltage: 12-36 VDC, Operating Temperature: -40~85°C, Isolated Voltage: 1000 VDC

Software： Predision_CANBUS_Converter_HECS-T-006_Software_EN.zip

Manuals ： Predision_Converter_HECS-T-006_UM_EN.pdf

Datasheet ： Predision_Converter_HECS-T-006_DS_EN.pdf

Quick Installation Guide： Predision_Converter_HECS-T-006_QIG_EN.pdf

LineCard： Predision_Line_Card_M2M_Connectivities.pdf
